| Form Factor |
2U |
| Processor |
- Number of Processors: 2
- Processor Type: 5th/4th Gen Intel® Xeon® Scalable Processors
- Max. TDP Support: 350W
|
| GPU |
2 × Dual-Slot PCIe GPUs (up to 300W) |
| Memory |
- Total Slots: 32
- Memory Type:
- 1DPC: DDR5 RDIMM up to 6400 MT/s
- 2DPC: DDR5 RDIMM up to 5200 MT/s
- DIMM Capacity:
|
| Expansion Slots |
SKU-#1
- 1 × OCP 3.0 NIC
- 2 × PCIe 5.0 x16, FHFL
- 3 × PCIe 5.0 x8, FHFL
- 2 × PCIe 5.0 x8, HHHL
|
| Storage Bays |
SKU-#1
- 8 × 3.5″ HDD + 2 × 2.5″ SSD
SKU-#2
SKU-#3
- 16 × 2.5″ SATA/SAS + 8 × U.2 NVMe SSD
|
| Onboard Storage |
1 × M.2 SSD 2280/22110 |
| Management |
Aspeed® AST2600 Management Controller |
| Security |
|
| Networking Interface |
- 1 × OCP 3.0 NIC
- 1 × RJ45 Dedicated IPMI LAN
- 1 × RJ45 1GbE
|
| Front I/O Ports |
- 2 × USB 2.0
- 1 × VGA
- 1 × Power Button
- 1 × ID Button
|
| Rear I/O Ports |
|
| OS Support |
- Windows Server 2022
- RHEL 9.1
- Ubuntu 22.04 LTS
|
| Power Supply |
1+1 2000W CRPS |
| Fans |
6 × 6056 Fans |
| Operating Environment |
- Operating Temperature: 5°C to 35°C
- Operating Humidity: 10%-90% (non-condensing)
- Non-operating Temperature: -40°C to 70°C
- Non-operating Humidity: 55%-85% (non-condensing)
|
| Chassis Dimensions (W × H × D) |
17.2″ × 3.4″ × 30.3″ / 438mm × 87mm × 770.2mm |
